Brand Name : XCMG
Model Number : XS103H
Certification : IOS/CE
Place of Origin : Jiangsu, China (Mainland)
MOQ : 1
Price : Call for price
Payment Terms : T/T
Delivery Time : 7-15days
Packaging Details : Container or Shipped by Ro-Ro or Bulk shipment
| Model: Road Roller | Condition: Brand New | Application: Construction |
| Brand Name: XCMG | Model Number XS103H | Certification: ISO,CE |
| Operating Weight: 10600kgs | Static Linear Load: 216N/cm | Dimension: 6150×2300×3200mm |
| Working speed: 7.3 km//h | Vibration Frequencyr:30/35Hz | Place of Origin: Jiangsu, China (Mainland) |
| Warranty: 1 year | Nominal amplitude: 1.9/0.95mm | After-sales Service Provided: Engineers available to service machinery overseas |
| Item | Content | Unit | XS103H |
| Weights | Operating weight | kg | 10600 |
| Maximum operating weight | kg | 10900 | |
| Front axle weight | kg | 4700 | |
| Rear axle weight | kg | 5900 | |
| Static linear load | N/cm | 216 | |
| Maneuverability | Working speed(F/R) | km/h | 7.3 |
| Gradeability | % | 40 | |
| Minimum turning radius(outer) | mm | 6400 | |
| Minimum ground clearance | mm | 447 | |
| Wheelbase | mm | 3040 | |
| Steering angle | 33 | ||
| Oscillation angle | 10 | ||
| Compaction | Vibration frequency | Hz | 30/35 |
| Nominal amplitude | mm | 1.9/0.95 | |
| Excitation force (high/low frequency) | kN | 220/150 | |
| Drum diameter | mm | 1513 | |
| Drum width | mm | 2130 | |
| Engine | Model | SC4H135G2 | |
| Emission | China stage I| | ||
| Rated power | kW | 100 | |
| Rated speed | r/min | 2200 | |
| Tire | Spec. | - | 20.5-25-16PR |
| Ply rating | 16 | ||
| Air pressure | kPa | 200 | |
| Capacities | Fuel tank | L | 255 |
| Urea tank | L | - |

|
|
10ton XCMG XS103H Road Roller China stage I|I Road Construction Equipment Images |
